Smart Digital Measurement Sensors: Distance Measurement with Extensive Flexibility

As industrial automation evolves, the demand for precise distance measurement, easy configuration, and intelligent diagnostics continues to grow. Smart Digital Measurement Sensors (DMS) are designed to meet these demands—combining high-resolution performance with advanced configurability and seamless system integration.

High-Resolution Distance Measurement You Can Trust

At the core of Smart DMS technology is high-resolution distance measurement, delivering accurate, linear, and continuous target-distance data. A linear digital output ensures precise signal representation, making these sensors ideal for applications that require exact positioning, monitoring, and quality control.

Configurable Outputs for Maximum Application Flexibility

Smart Digital Measurement Sensors feature two fully configurable outputs, enabling one sensor to adapt to many use cases:

• Teachable switching signals for fast and intuitive setup
• Dual outputs with analog or digital options for flexible control-system integration
• Output on Pin 2 configurable as either an additional output, an input, or a wire-teach interface

This dual-output concept simplifies both new installations and retrofits, reducing wiring effort and system complexity.

Advanced User Configurability

Extensive configuration options allow users to fine-tune sensor behavior directly to application needs:

• Stretch, delay, and one-shot timers for precise signal control
• Event-based alarms supporting smarter process responses
• Counter functions and temperature monitoring for enhanced diagnostics
• Data storage to retain settings and process information

These features enable engineers to move beyond basic sensing toward intelligent process optimization.

Built for Smart Automation and IIoT

With integrated data and diagnostic capabilities, Smart DMS devices support IIoT-ready architectures. Condition-based and event-driven alarms allow early detection of deviations, forming the basis for predictive maintenance and reduced downtime.

Robust Design for Demanding Environments

To ensure reliability in harsh industrial conditions, Smart Digital Measurement Sensors are available with:

• Stainless steel V2A housing for corrosion resistance
• High-pressure versions for challenging mechanical environments

These rugged options maintain exceptional sensing performance while providing long service life.

Measure. Monitor. Configure. Predict.

Smart Digital Measurement Sensors deliver the precision of high-resolution distance measurement, the power of user configurability, and the flexibility of dual outputs—all in one intelligent solution.
